Qnap Storage Tvs Ec2480U Sas RP R2
QNAP TVS-EC2480U-SAS-RP R2 is the world’s first unified NAS supporting Auto Tiering to deliver ongoing optimization of data across high-performance SSD, 12Gbps SAS drives and high-capacity SATA disks. Powered by an Intel® Xeon E3 CPU, the 40GbE-ready TVS-EC2480U-SAS-RP R2 delivers exceptional perfor…
- توضیحات
- اطلاعات بیشتر
توضیحات
Qnap Storage Tvs Ec2480U Sas RP R2
QNAP TVS-EC2480U-SAS-RP R2 is the world’s first unified NAS supporting Auto Tiering to deliver ongoing optimization of data across high-performance SSD, 12Gbps SAS drives and high-capacity SATA disks. Powered by an Intel® Xeon E3 CPU, the 40GbE-ready TVS-EC2480U-SAS-RP R2 delivers exceptional performance and supports cross-platform file sharing, comprehensive backup solutions, iSCSI & virtualization applications, and more practical business functions. With the powerful QTS operating system, the TVS-EC2480U-SAS-RP R2 performs as a reliable, scalable and unbeatable unified and tiered storage solution for businesses.
Built-in 10GbE, highly-efficient storage solution with high speed network for HD video editing and sharing3,800+ MB/s throughput and 267,000+ IOPSQtier Technology drives Auto Tiering for optimal storage efficiencyBuilt-in 256GB mSATA modules for caching, beneficial to IOPS-demanding applicationsScalable design, up to 1,216 TB total capacityVirtualization-ready, centralized data storage, backup, sharing and disaster recoveryBackward compatible with SAS/SATA 6Gbps drives
اطلاعات بیشتر
| Relative Humidity | 5~95% non-condensing, wet bulb: 27˚C. |
|---|---|
| CPU | Intel® Xeon® E3-1246 v3 Family 3.5 GHz Quad-core Processor |
| Temperature | 0-40˚C |
| Memory | please refer to the QNAP RAM Module Installation Guide, the original 4GB RAM modules must be removed. For the information of RAM module installation and compatible NAS models |
| USB | 4x USB 3.0 port (rear) 4x USB 2.0 port (rear) Support USB printer, and USB UPS etc., pen drive, USB hub |
| Hard Drive | 24 x 3.5-inch SAS 12Gbps, please visit https://www.qnap.com/com, SAS/SATA 6Gbps/3Gbps hard drive or 2.5-inch SAS/SATA SSD hard drive NOTE: The standard system is shipped without hard drives. For the hard drive compatibility list |
| PCIe Slot | 2 (Right slot: 1* PCIe Gen3 x8; Left slot: 1* PCIe Gen3 x4) Note: The PCIe Gen3 x8 slot is occupied by a 10GbE network adapter. |
| Form Factor | 4U, rackmount |
| Weight | Net weight (NAS only) : 23.08 kg/50.88 lb Gross weight (with packing and accessories) : 28.56 kg/ 62.96 lb |
| Power Consumption | Sleep mode: 129.43 In Operation: 263.81 W (with 24 x HITACHI HUS724020ALA640 hard drive installed |
| LAN Port | Built-in 2 x 10 GbE SFP+ ports (LAN-10G2SF-MLX) and 4 x GbE ports 40GbE is optional Note: 1. For the optional network card compatibility list, please refer to chapter 6 in the Turbo NAS Hardware Manual., please visit Compatibility list 2. For the information of network card installation |
| Internal Cache Port | please visit http://shop.qnap.com/, Two mSATA port on board for read caching. The standard system is shipped with two 128GB mSATA flash. For the optional mSATA flash |
| Hard Drive Tray | 24 x hot-swappable and lockable tray |
| Flash Memory | 512MB DOM |
| Sound Level | Sound Level (dB) Sound pressure (LpAm) (bystander position): 36.2 dB (with 24 x HITACHI HUS724020ALA640 hard drive installed) |
| Dimensions | 176.15(H) x 442.5(W) x 530.5(D) mm 6.94(H) x 17.42(W) x 20.89(D) inch |
| Fan | 4 x 8 cm smart cooling fan |
| Power Supply | Redundant power: Input 90~264VAC; 650W x 2 |
| Alarm Buzzer | System warning |
| Buttons | System: Power button and reset button |
| LED Indicators | 10 GbE, LAN, Status, storage expansion port status |
